Product information

air shower tunnel

product name: air shower tunnel
Product number: DSX-air shower tunnel01
Products Exhibitors: DSX
Product Documentation: No Related Documents

a brief introdction

Deshengxin air shower tunnel is supporting equipment for clean room and workshop. It can remove the dust adhering of the operator man-machine dialogue interface makes operation chain, such as real-time monitoring state oods and block the unclean air into the working area as an air lock.


air shower tunnel  Detailed description of


Air shower tunnle factory -Deshengxin air shower tunnel Characteristics
1. Special ultrathin blowing tube housing and fan, match with rotatable embedded stainless steel nozzle, greatly increased the space utilization and blowing tube effect
2. Built-in many sets of operating procedures, can be convenient and flexible call. Intelligent man-machine dialogue interface makes operation chain, such as real-time monitoring state.
3. Standard of the modular design, make field assembly faster and more convenient maintenance.

Air shower tunnel Material:
Outside case: 1.2mm cold rolled steel with powder coated or staniless steel(SUS#201 OR 304)
Inside case: 1.2mm cold rolled steel with powder coated or staniless steel(SUS#201 OR 304)
Doors: SUS#201,SUS#304 or aluminum alloy
Base: SUS#201 or 304
Nozzles:SUS#304

 Air shower tunnel Features:
1. The control system run automatically, the two doors electronically interlocked, with photoelectric sensor
  (One door in open state, the other door must in close state. When people enter air shower, the system will shower automatically by photoelectric sensor)
2. Air shower time from 0 to 99 seconds which can be adjustable
3. Pre filter and HEPA filter

 Air shower tunnels Control system:

 LCD control panel, electronic interlock and automatic blowing by photoelectronic sensor.

 Air shower Optional accessor:
1.Manul swing door,automatic sliding door or high speed scroll door
2.HEPA filter or ULPA filter
3. The case is used of cold-rolled steel plate / all stainless steel air shower / just stainless steel inside
4. Common fluorescent lamp / UV Sterilizer lamp
5.  With voice announce



 Air shower Standar size and specificaton:



Model



Air shower

DSX-FL-1200

DSX-FL-1400

DSX-FL-1500

 External dimensions (mm)

1200x1000x 2150

1400x1000x 2150

1400x1500x 2150

 Dimensions in WxDxH(mm)

800x920x 1950

800x920x 1950

800x1400x 1950

Material for case

Cold rolled steel with powder coated , SUS#201 or SUS#304

 Suitable person

1

1

2

 Nozzles

6(one side)

12(two sides)

18(two sides)

 Blow power(W)

1100

2200

2500

HEPA filter’s dimensions

610x610x50 One piece

610x610x69 two piece

610x610x69 two piece

 Nozzle diameter

30mm

 Air shower time

0~99s Adjustable

 Spurt wind speed

25m/s(+-20%)

Voltage

380V/50Hz/3Ph; 220V/50Hz/1Ph

hepa Filter efficiency

                                     Above 99.99% efficient on 0.3um particles

Control system

LCD control panel, electronic interlock and automatic blowing

Customer’s sizes and specifications are welcome.
