clean room Stainless steel air shower

  • Products name:clean room Stainless steel air shower
  • Products nubmer:DSX-AIR SHOWER 01
  • Products Exhibitors:DSX
  • Product Documentation:
你添加了1件商品 查看购物车
a brief introdction
WuJiang Deshengxin DSX clean room Stainless steel air shower,Standard-Profile Straight-Through Air Showers quickly and effectively remove particles that will otherwise be carried into your cleanroom. Our decontamination air showers feature rugged construction and adjustable, high velocity air jets.

clean room Stainless steel air shower

的详细介绍
Deshengxin SS air shower (Stainless steel air showr) use high quality stainless steel for our case of air shower and our stainless steel air shower will have following features:
using high quality stainless steel materials and advanced CNC machine to produce the box of our air shower. This can make sure our products with smooth and elegant surface.
Adjustable DSX air nozzles on walls and ceiling shall be white plastic construction sized and spaced to provide an average of 6000 - 7,000 fpm air flow at the face of the nozzle.
Return air registers at floor level on walls shall be anodized aluminum with 1” pleated MERV 7 prefilters.
Anodized aluminum entry and exit doors with push/pull hardware, hydraulic door closures and acrylic, polycarbonate or safety glass inserts.
using the fully visual glasses for our stainless steel door to make sure the strength & beauty.
DSX air shower  can Single side blowing and using photo-electric sensor to keep automatically blowing.
with electronic interlock and sanded stainless steel floor.
with DSX multiple stainless steel nozzle and low noise & large volume centrifugal fan.

Standar air shower size and specificaton:


Model


Air shower

DSX-FL-1200

DSX-FL-1400

DSX-FL-1500

External dimensions (mm)

1200x1000x 2150

1400x1000x 2150

1400x1500x 2150

Dimensions in WxDxH(mm)

800x920x 1950

800x920x 1950

800x1400x 1950

Material for case

Cold rolled steel with powder coated , SUS#201 or SUS#304

Suitable person

1

1

2

Nozzles

6(one side)

12(two sides)

18(two sides)

Blow power(W)

1100

2200

2500

HEPA filter’s dimensions

610x610x50 One piece

610x610x69 two piece

610x610x69 two piece

Nozzle diameter

30mm

Air shower time

0~99s Adjustable

Spurt wind speed

25m/s(+-20%)

Voltage

380V/50Hz/3Ph; 220V/50Hz/1Ph

hepa Filter efficiency

Above 99.99% efficient on 0.3um particles

Control system

LCD control panel, electronic interlock and automatic blowing

Non-standard design and dimensions are available.
