RIGHT ANGLE PASSAGE AIR SHOWER

Products name：RIGHT ANGLE PASSAGE AIR SHOWER
Products nubmer：DS-AS1400
Products Exhibitors：DSX
Product Documentation：

你添加了1件商品查看购物车

a brief introdction

RIGHT ANGLE PASSAGE AIR SHOWER is supporting equipment for clean room and workshop. It can remove the dust adhering of the operator/gIntelligent man-machine dialogue interface makes operation chain, such as real-time monitoring state oods and block the unclean air into the working area as an air lock.

RIGHT ANGLE PASSAGE AIR SHOWER

的详细介绍

Deshengxin offer different types of Air Showers, Straight Thru Passage, Right Angle Passage and 3-door passage. These units are also available in a Low-profile where the motor blower and HEPA Module are alongside the base unit instead of on top of the base. Units can be coupled together to create a Tunnel configuration for passage of large groups of personnel.

Choose the correct type for your application or call to one of our experienced sales engineers for assistance.

RIGHT ANGLE PASSAGE AIR SHOWER size and specificaton:

Model	right angle passage Air shower
Model	DSX-FL-1200	DSX-FL-1400	DSX-FL-1500
External dimensions (mm)	1200x1000x 2150	1400x1000x 2150	1400x1500x 2150
Dimensions in WxDxH(mm)	800x920x 1950	800x920x 1950	800x1400x 1950
Material for case	Cold rolled steel with powder coated , SUS#201 or SUS#304
Suitable person	1	1	2
Nozzles	6(one side)	12(two sides)	18(two sides)
Blow power(W)	1100	2200	2500
HEPA filter’s dimensions	610x610x50 One piece	610x610x69 two piece	610x610x69 two piece
Nozzle diameter	30mm
Air shower time	0~99s Adjustable
Spurt wind speed	25m/s(+-20%)
Voltage	380V/50Hz/3Ph; 220V/50Hz/1Ph
hepa Filter efficiency	Above 99.99% efficient on 0.3um particles
Control system	LCD control panel, electronic interlock and automatic blowing

Non-standard design and dimensions are available.
