Horizontal flow clean bench
- Products name：Horizontal flow clean bench
- Products nubmer：DSX-CB995
- Products Exhibitors：DSX
- Product Documentation：
Horizontal flow clean bench
的详细介绍
Clean Bench is a kind of clean room equipment which meets strict demands for working environment. It can provide 100-level cleanness for partial clean area. It provides high cleanness and can move easily. Clean bench is widely used in optics, biochemistry, microelectronics, precision instrument etc. Clean bench can be classified into vertical flow and horizontal flow. And also vertical flow clean bench can be divided into single side operation, double operation & air returning type.
DSX Clean Benches Features:
1. Clean Bench is separate from the frame of clean bench, therefore there is no vibration.
2. Clean Bench use stainless steel as material which is wear resistant and easy to clean.
3. The bottom of the clean bench use universal wheels which is easy to move and install
4. The clean bench use high quality fan system which has features such as long service life, low noise, free-maintenance, small vibration, stable performance etc. The fan can rotate more than 50,000 hours.
5. The clean bench use continuous variable transmission to keep ideal air speed.
6. Non-standard sizes are welcome.
DSX Clean bench parameters:
1.Single operation vertical flow clean bench( Vertical Laminar Flow Hoods Air Flow Diagram) parameters
|
Item No.
|
DSX-CBS-1040 |
DSX-CBS-1340 |
DSX-CBS-1640 |
DSX-CBS-1950 |
||
|
Size |
W (w1)mm |
1040(950) |
1340(1250) |
1640(1550) |
1950(1860) |
|
|
D (D1)mm |
740(645) |
740(645) |
740(645) |
740(645) |
||
|
H (H1)mm |
2050(800) |
2050(800) |
2050(800) |
2050(800) |
||
|
Volume（M3/h） |
905 |
1350 |
1650 |
1950 |
||
|
velocity（m/s） |
0.45±20% |
|||||
|
cleanness |
CLASS100(USA Federal Standard209E） |
|||||
|
HEPA Efficiency |
99.99%（0.3um） |
|||||
|
HEPA size(mm) |
915*610*70 |
1220*610*70 |
915*610*70 610*610*70 |
915*610*70 |
||
|
HEPA quantity |
1 |
1 |
1/1 |
2 |
||
|
PRE FILTER size |
495*495*45mm |
595*595*45mm |
495*495*45mm |
|||
|
PRE FILTER quantity |
1 |
1 |
1 |
2 |
||
|
Vibration half peak value |
Work table and clean bench frame is separate, no effect on vibration |
|||||
|
Work table material |
Sanding stainless steel |
|||||
|
Noise |
＜58db |
＜58db |
＜60db |
＜62db |
||
|
Noise test position |
20cm in front of clean bench, 1.2m to the floor |
|||||
|
Power |
160W |
180W |
260W |
280W |
||
|
Person |
1 |
1～2 |
2～3 |
3～4 |
||
|
Power supply |
230ACV—50Hz |
|||||
2.Double side vertical flow clean bench parameters
|
Item No. |
DSX-D-1340 |
DSX-D-1640 |
DSX-D-1950 |
|
|
size |
W (w1)mm |
1340(1340) |
1640(1640) |
1950(1950) |
|
D (D1)mm |
1450(1350) |
1450(1350) |
1450(1350) |
|
|
H (H1)mm |
2050(800) |
2050(800) |
2050(800) |
|
|
volume（M3/h） |
2500 |
3200 |
3700 |
|
|
velocity（m/s） |
0.45±20% |
|||
|
Cleanness |
CLASS100(USA Federal Standard209E） |
|||
|
HEPA Efficiency |
99.99%（0.3um） |
|||
|
HEPA Size |
122*610*70 |
915*610*70 610*610*70 |
915*610*70 |
|
|
HEPA quantity |
2 |
2/2 |
4 |
|
|
PRE FILTER size |
495*495*45/paper |
595*595*45/ paper |
495*495*45/ paper |
|
|
PRE FILTER quantity |
2 |
2 |
4 |
|
|
Vibration half peak value |
Work table and clean bench frame is separate, no effect on vibration |
|||
|
Work table material |
Sanding stainless steel |
|||
|
Noise |
＜60db |
＜62db |
＜62db |
|
|
Noise test position |
20cm in front of clean bench, 1.2m to the floor |
|||
|
Power |
360W |
520W |
560W |
|
|
Person |
2～4 |
4～6 |
6～8 |
|
|
Power supply |
230ACV—50Hz |
|||
3.Horizontal flow clean bench(Horizontal Laminar Flow Hoods Air Flow Diagram) parameters
|
Item No.
|
DSX-HF-995 |
DSX-HF-1300 |
DSX-HF-1605 |
DSX-HF-1910 |
||
|
size |
W (w1)mm |
995(915) |
1300(1220) |
1605(1525) |
1910(1830) |
|
|
D (D1)mm |
850(550) |
850(550) |
850(550) |
850(550) |
||
|
H (H1)mm |
1480(610) |
1480(610) |
1480(610) |
1480(610) |
||
|
volume（M3/h） |
905 |
1250 |
1550 |
1850 |
||
|
velocity（m/s） |
0.45±20% |
|||||
|
Cleanness |
CLASS100 |
|||||
|
HEPA Efficiency |
99.99%（0.3um） |
|||||
|
HEPA Size |
915*610*70 |
1220*610*70 |
915*610*70 610*610*70 |
915*610*70 |
||
|
HEPA quantity |
1 |
1 |
1/1 |
2 |
||
|
Work table material |
Sanding stainless steel |
|||||
|
Noise |
＜58db |
＜58db |
＜60db |
＜62db |
||
|
Noise test position |
20cm in front of clean bench, 1.2m to the floor |
|||||
|
Power |
160W |
180W |
260W |
280W |
||
|
Person |
1 |
1～2 |
2～3 |
3～4 |
||
|
Power supply |
230ACV—50Hz |
|||||
4.Air returning type clean bench parameters
| item NO. |
Dsx-AR-995 |
Dsx-AR-1300 |
Dsx-AR-1605 |
Dsx-AR-1910 |
|
|
size |
W (w1)mm |
995(915) |
1300(1220) |
1605(1525) |
1910(1830) |
|
D (D1)mm |
850(600) |
850(600) |
850(600) |
850(600) |
|
|
H (H1)mm |
1800(650) |
1800(650) |
1800(650) |
1800(650) |
|
|
volume（M3/h） |
905 |
1250 |
1550 |
1850 |
|
|
velocity（m/s） |
0.45±20% |
||||
|
Cleanness |
CLASS100(USA Federal Standard209E） |
||||
|
HEPA Efficiency |
99.99%（0.3um） |
||||
|
HEPA Size |
915*610*70 |
1220*610*70 |
915*610*70 610*610*70 |
915*610*70 |
|
|
HEPA quantity |
1 |
1 |
1/1 |
2 |
|
|
PRE FILTER size |
495*495*45/paper |
495*495*45/ paper |
495*495*45/ paper |
495*495*45/ paper |
|
|
PRE FILTER quantity |
2 |
3 |
3 |
5 |
|
|
Work table material |
Sanding stainless steel |
||||
|
Noise |
＜58db |
＜58db |
＜60db |
＜62db |
|
|
Noise test position |
20cm in front of clean bench, 1.2m to the floor |
||||
|
Power |
160W |
180W |
260W |
280W |
|
|
Person |
1 |
1～2 |
2～3 |
3～4 |
|
|
Power supply |
230ACV—50Hz |
||||
Exhibition
1.Factory direct sale, OEM, ODM available , R&D department available .
2.Experienced manufacture, own provided motor, fan, enclosure etc., Controlling quality, price and delivery term much better.
3.Strictly testing equipment, full-experienced technicians ,quality guaranteed .
4.good after-sale service.
5.we are the ISO9001 approval enterprise. Our products obtain CCC and CE certificate as well.
