Three-door air shower for clean room
- Products name:Three-door air shower for clean room
- Products nubmer:DSX Clean room air shower01
- Products Exhibitors:DSX
- Product Documentation:
Three-door air shower for clean room
的详细介绍
Three-door clean room air shower is a kind of partial clean equipment with rather strong universality and is installed at the area between the clean and non-clean rooms.
1. Special ultrathin blowing tube housing and fan, match with rotatable embedded stainless steel nozzle, greatly increased the space utilization and blowing tube effect
2. Built-in many sets of operating procedures, can be convenient and flexible call. Intelligent man-machine dialogue interface makes operation chain, such as real-time monitoring state.
3. Standard of the modular design, make field assembly faster and more convenient maintenance.
4.According to user needs and site condition transformation function and form.
Model
|
Air shower
|
||
DSX-FL-1200
|
DSX-FL-1400
|
DSX-FL-1500
|
|
External dimensions (mm)
|
1200x1000x 2150
|
1400x1000x 2150
|
1400x1500x 2150
|
Dimensions in WxDxH(mm)
|
800x920x 1950
|
800x920x 1950
|
800x1400x 1950
|
Material for case
|
Cold rolled steel with powder coated , SUS#201 or SUS#304
|
||
Suitable person
|
1
|
1
|
2
|
Nozzles
|
6(one side)
|
12(two sides)
|
18(two sides)
|
Blow power(W)
|
1100
|
2200
|
2500
|
HEPA filter’s dimensions
|
610x610x50 One piece
|
610x610x69 two piece
|
610x610x69 two piece
|
Nozzle diameter
|
30mm
|
||
Air shower time
|
0~99s Adjustable
|
||
Spurt wind speed
|
25m/s(+-20%)
|
||
Voltage
|
380V/50Hz/3Ph; 220V/50Hz/1Ph
|
||
hepa Filter efficiency
|
Above 99.99% efficient on 0.3um particles
|
||
Control system
|
LCD control panel, electronic interlock and automatic blowing
|
Different size and specifications can be customized according to individual client’ requirements!
