所在位置: Home> Product Class> Clean bench>

Single operation vertical flow clean bench

  • Products name: Single operation vertical flow clean bench
  • Products nubmer:DSX-S-1040
  • Products Exhibitors:DSX
  • Product Documentation:
你添加了1件商品 查看购物车
a brief introdction
DSX is a leading name that offers precision engineered Laminar Flow Benches or Laminar Flow Workstations to its customers. These products are manufactured in line with the defined quality standards so as to be sure of their optimum quality. Designed with perfection.

Single operation vertical flow clean bench

的详细介绍

Clean Bench is a kind of clean room equipment which meets strict demands for working environment. It can provide 100-level cleanness for partial clean area. It provides high cleanness and can move easily. Clean bench is widely used in optics, biochemistry, microelectronics, precision instrument etc. Clean bench can be classified into vertical flow and horizontal flow. And also vertical flow clean bench can be divided into single side operation, double side operation & air returning type.



 Single operation vertical flow clean bench parameters

Item No.



DSX-S-1040

DSX-S-1340

DSX-S-1640

DSX-S-1950

Size

W (w1)mm

1040(950)

1340(1250)

1640(1550)

1950(1860)

 D (D1)mm

740(645)

740(645)

740(645)

740(645)

 H (H1)mm

2050(800)

2050(800)

2050(800)

2050(800)

VolumeM3/h

905

1350

1650

1950

velocitym/s

0.45±20%

cleanness

CLASS100(USA Federal Standard209E

HEPA Efficiency

99.99%0.3um

HEPA size

915*610*70

1220*610*70

915*610*70

610*610*70

915*610*70

HEPA quantity

1

1

1/1

2

PRE FILTER size

495*495*45/paper

595*595*45/ paper

495*495*45/ paper

PRE FILTER quantity

1

1

1

2

Vibration half peak value

Work table and clean bench frame is separate, no effect on vibration

Work table material

         Sanding stainless steel

Noise

58db

58db

60db

62db

Noise test position

20cm in front of clean bench,

1.2m to the floor

Power

160W

180W

260W

280W

Person

1

12

23

34

Power supply

230ACV—50Hz


   Single operation vertical flow clean bench :
1. Work table is separate from the frame of clean bench, therefore there is no vibration.
2. Work table use stainless steel as material which is wear resistant and easy to clean.
3. It is suitable for forming clean production line, and the cleanness can reach to 100 according to individuals’ requirements.
4. The clean bench use DSX fan system which has features such as long service life, low noise, free-maintenance, small vibration, stable performance etc. The fan can rotate more than 50,000 hours.
5. The clean bench use continuous variable transmission to keep ideal air speed.

Alternative accessories:

1. ULPA

2. Stainless steel work table

3. overhead door

4. Microcomputer control, touch key, digital display




Our Services:



Factory testing (all the sets you ordered):

All of equipment is individually factory tested for safety and performance in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the unit’s individual results for each unit.



Factory test include:

--appearance testing

--functional test and visual inspection

--electrical safety tests

--air velocity testing

--noise testing

 Advantage:
1. Remote control. The operator need not to contact the biological safety cabinet directly, it's favorable for preventing cross contamination. It also makes the control operation much easier and convenient.
2. Foot Switch. Within the range of the activity, we could use foot switch to adjust the height of the front panel. It is our unique design.
3. Work area surrounded by negative pressure.
4. Timer function
5. VFD display
6. Filter life inquiry
7. Safety power lock
8. Motor control front window
9. OEM work available
