Double side vertical flow clean bench

Double side vertical flow clean bench
1. Work table is separate from the frame of clean bench, therefore there is no vibration.
2. Work table use stainless steel as material which is wear resistant and easy to clean.
3. It is suitable for forming clean production line, and the cleanness can reach to 100 according to individuals’ requirements.
4. The clean bench use EBM fan system which has features such as long service life, low noise, free-maintenance, small vibration, stable performance etc. The fan can rotate more than 50,000 hours.
5. The clean bench use continuous variable transmission to keep ideal air speed.

Alternative accessories:
1. ULPA
2. Stainless steel work table
3. overhead door
4. Microcomputer control, touch key, digital display
5. timer
Double side vertical flow clean bench parameters

		DSX-D-1340	DSX-D-1640	DSX-D-1950
size	W (w1)mm	1340(1340)	1640(1640)	1950(1950)
	D (D1)mm	1450(1350)	1450(1350)	1450(1350)
	H (H1)mm	2050(800)	2050(800)	2050(800)
volume（M3/h）		2500	3200	3700
velocity（m/s）		0.45±20%
Cleanness		CLASS100(USA Federal Standard209E）
HEPA Efficiency		99.99%（0.3um）
HEPA Size		122*610*70	915*610*70 610*610*70	915*610*70
HEPA quantity		2	2/2	4
PRE FILTER size		495*495*45/paper	595*595*45/ paper	495*495*45/ paper
PRE FILTER quantity		2	2	4
Vibration half peak value		Work table and clean bench frame is separate, no effect on vibration
Work table material		Sanding stainless steel
Noise		＜60db	＜62db	＜62db
Noise test position		20cm in front of clean bench,  1.2m to the floor
Power		360W	520W	560W
Person		2～4	4～6	6～8
Power supply		230ACV—50Hz
